Sanitary Stainless Steel Auto Tri Clamp Three Way Ball Valve

The Auto three way ball valve with ISO5211 mounting pad, the pneumatic and electric actuators can be installed.

Brand:
J&O
Material:
SS304 / SS316L
Connection:
Clamp
Gasket:
PTFE
Working Temperature:
-20°~120°
Working Pressure:
0-10Bar
Enquiry
Auto Clamp Three Way Ball Valve
Auto Clamp Three Way Ball Valve Auto Clamp Three Way Ball Valve Auto Clamp Three Way Ball Valve Auto Clamp Three Way Ball Valve Auto Clamp Three Way Ball Valve

Sanitary Stainless Steel Auto Clamp Three Way Ball Valve

  • The Auto three way ball valve with ISO5211 mounting pad, the pneumatic and electric actuators can be installed.
  • This Three Way Ball Valve is our improvement for the Lithium Battery industry. A bolt can be added to the bottom of the ball valve to fix the ball. When operating the valve, the ball will not shift. This three way ball valve is also improved internally, which is different from ordinary three way ball valve.

Technical Data

Valve Body Material: SS304/SS316L
Seal Material: PTFE
Mex working pressure: 10Bar
Max. Working Temperature: 180 degree C
Availably size: 1"-4", DN25-DN100
Availably connection: Clamp
Availably standard: 3A/DIN/SMS/RJT/ISO/IDF
Certificate: ISO, PED/97/23/EC, FDA.177.2600
